Aura DHI-PHZ5-WGP-P31.25-001
Grid screen
Unique Features
- Flexible grid screen series products are specially designed for outdoor landscape lighting a flexible grid screen, pixel spacing.
- 32mm,50mm,55mm,62.5mm,83.3mm,100mm, etc. can be used for outdoor media facade display, support modular customization, simple and reliable installation.
- Design of new generation serial redundancy control technolog.
- High transparency, high waterproof, high appearance design
- Full angle, high brightness, multi view effect design.
- Flexible structure design, adapt to a variety of different media facade display applications.
- Outdoor lightning protection and electrostatic discharge (ESD) protection.
Technical Specifications
Model
DHI-PHZ5-WGP-P31.25-001
Pixel Pitch
31.25*31.25
Pixel Configuration
1R1G1B
LED Type
SMD2727
Color Temperature
RGB
Viewing Angle
75°
Pixel Density
1024 dots/m²
Module Size
500mm×1000mm
Module Resolution
16×32 dots
Working Voltage
DC 12V
Control mode
DMX512/RBT
IP Rating
IP66
Operating Temperature/ Humidity
-40°C-60°C/10~90%RH
Storage Temperature/ Humidity
-40°C-70°C/10~90%RH
Grayscale
4096
Refresh frequency
2KHz
Surface brightness
4500cd/㎡
Lamp Lifespan
≥50,000 H
